| 组件名称 | Package1
(PH) | Package2
(Standard)
| Package3
(Pathology)
|
| 目镜 | 目镜 N-WF10X/22，视度可调，护眼罩 | ⬤ | ⬤ | ⬤ |
| 观察头 | 30°铰链三目观察头（分光比100：0、20：80 ） | ⬤ | ⬤ | ⬤ |
| 转换器 | 5 孔转换器 | ⬤ | ⬤ | ⬤ |
EC-H
Objective
| CCIS EC-H Plan4X/0.1, W.D=15.9mm | ⬤ | ⬤ | ⬤ |
| CCIS EC-H Plan10X/0.25, W.D=17.4mm | ⭘ | ⬤ | ⬤ |
| CCIS EC-H Plan20X/0.45, W.D=0.9mm | ⭘ | ⭘ | ⬤ |
| CCIS EC-H Plan40X/0.65, W.D=0.5mm | ⭘ | ⬤ | ⬤ |
| CCIS EC-H Plan 60X/0.80, W.D=0.35mm | ⭘ | ⭘ | ⭘ |
| CCIS EC-H Plan100X(oil)/1.25, W.D=0.15mm | ⬤ | ⬤ | ⭘ |
EC-H Phase
Objective
| CCIS EC-H PL Ph10X-Ph1/0.25, W.D=17.4mm | ⬤ | _ | _ |
| CCIS EC-H PL Ph20X-Ph2/0.45, W.D=0.9mm | ⭘ | _ | _ |
| CCIS EC-H PL Ph40X-Ph2/0.65, W.D=0.5mm | ⬤ | _ | _ |
| CCIS EC-H PL Ph100X(oil)-Ph3/1.25, W.D=0.15mm | ⭘ | _ | _ |
Plan UC
Objective
| Plan UC 4X/0.1, W.D=30.5mm | ⭘ | ⭘ | ⭘ |
| Plan UC 10X/0.25, W.D=17.4mm | ⭘ | ⭘ | ⭘ |
| Plan UC 20X/0.45,W.D=0.8mm | ⭘ | ⭘ | ⭘ |
| Plan UC 40X/0.65,,W.D=0.6mm | ⭘ | ⭘ | ⭘ |
| Plan UC 60X/0.8,W.D=0.35mm | ⭘ | ⭘ | ⭘ |
| Plan UC 100X/1.25 Oil,W.D=0.16mm | ⭘ | ⭘ | ⭘ |
| Plan UC 100X/0.8,W.D=1.7mm | ⭘ | ⭘ | ⭘ |
相衬物镜
| Plan UC 10X/0.25, W.D=17.4mm | ⭘ | ⭘ | ⭘ |
| Plan UC 20X/0.45,W.D=0.8mm | ⭘ | ⭘ | ⭘ |
| Plan UC 40X/0.65,,W.D=0.6mm | ⭘ | ⭘ | ⭘ |
| Plan UC 100X/1.25 Oil,W.D=0.16mm | ⭘ | ⭘ | ⭘ |
| 聚光镜 | N.A 0.9/1.25 Abbe condenser with slider slot | ⬤ | ⬤ | ⬤ |
| 载物台 | 钢丝载物台 | ⬤ | ⬤ | ⬤ |
| 照明 | 柯拉照明 | ⬤ | ⬤ | ⬤ |
透射光源
| LED 灯抽屉组 ( 高色温） | ⬤ | ⬤ | ⬤ |
| LED 灯抽屉组 ( 低色温） | ⭘ | ⭘ | ⭘ |
| 卤素灯抽屉组 | ⬤ | ⬤ | ⬤ |
接头
| 0.5X | ⭘ | ⭘ | ⭘ |
| 0.65X | ⭘ | ⭘ | ⭘ |
| 1X | ⭘ | ⭘ | ⭘ |
相衬和暗场附件
| C相衬推拉板组 (Ph1 和 Ph2) | ⬤ | _ | _ |
| 相衬推拉板（Ph1 | ⭘ | _ | _ |
| 相衬推拉板（Ph2 | ⭘ | _ | _ |
| 相衬推拉板 (Ph3) | ⭘ | _ | _ |
| 暗场推拉板 | ⭘ | _ | _ |
| 对中望远镜 | ⬤ | _ | _ |
检偏、起偏
| 检偏器 | ⭘ | ⭘ | ⭘ |
| 起偏器组 ( 置于集光镜上 ) | ⭘ | ⭘ | ⭘ |
滤色片
| 兰色滤色片 | ⬤ | ⬤ | ⬤ |
说明书
| 说明书 _PA43 | ⬤ | ⬤ | ⬤ |
