φ8 to 14 mm * We accept custom orders for the LED Light Sources that have different fiber bundle diameter. Please contact your CCS sales representative for details.
输入电压
100 to 240 VAC (±10%), 50/60 Hz [For usage in Japan: 100 VAC (±10%), 50/60 Hz]
消耗功率
200 VA typ. [For usage in Japan: 100 VAC, 180W]
对地泄漏电流
3.5 mA max. (264 VAC, 60 Hz, with no load) [For usage in Japan: 1 mA max. (100 VAC, 60 Hz, with no load)]
绝缘耐压・绝缘电阻(输入-FG)
1,500 VAC for one minute, cutoff current: 10 mA, 500 VDC, 20 MΩ min.
外壳材质
Aluminum alloy (black alumite)
适合规格
CE, UKCA, RoHS, IEC 62471 (High risk)
使用温湿度
Temperature: 5 to 40℃, Humidity: 20% to 80% (with no condensation) Altitude: 2,000 max., Transient overcurrent: Category II, Pollution level: 2
保存温湿度
Temperature: -15 to 60°C, Humidity: 20 to 85%RH (with no condensation)
冷却方式
强制冷却
重量
3,900 g max.
附属品
Instruction guide, 2-m 3-prong AC power cable with ground terminal
Program
【Sample Program】 Sample programs are available. See the 电源 tab.
