Light Units with 24 VDC input Total for 3 channels: 28 W
通道数
3 channels
发光方式
Constant/Strobe lighting
驱动方式
Constant lighting
调光方式
PWM control, Lighting time control
PWN频率
125kHz
输入电压
100 to 240 VAC (+10% -15%)
频率
50/60 Hz
消耗功率
78 VA
输出电压
24VDC
输出电流
Total for 3 channels: 1.1 A
涌入电流(typ)
15 A (at 100 VAC), 30 A (at 200 VAC) from a cold start
调光
Manual: 256-step using the front setting switch External: Command input via TCP/IP or UDP/IP communication
错误检测显示
OCP is displayed on the digital display
错误检测输出
Command sent when overcurrent output is detected.
过电流保护
Operates at 107% of rated output current or higher. Reset by pressing operation setting switch for at least 1 second or by cycling the power supply. *Do not intentionally short-circuit the positive and negative output terminals.
输出端口
SMP-03V-BC x 3
外部控制端口
Trigger input: MIL connector (MIL-C-83503 compliant), 10 pins For setting the light intensity/mode: RJ-45 connector
适合规格
CE, UKCA, RoHS
使用温湿度
Temperature: 0 to 40°C, Humidity: 20 to 85%RH (no condensation)
保存温湿度
Temperature: -20 to 60°C, Humidity: 20 to 85%RH (no condensation)
冷却方式
Natural air-cooling
重量
600 g
材质
Aluminium, ABS
附属品
2m long 3-prong AC power cord with ground terminal, Instruction Guide
Program
【Sample Program】 Sample programs are available. See the 选件 tab.
