Metal connectors: 24 V, 300 W (300 W max. per connector) EL connectors: 24 V, 300 W (150 W max. per connector) Total for all connectors: 300 W max.
通道数
1 channel
发光方式
常时发光
驱动方式
Constant lighting
调光方式
可变电压控制
输入电压
100 to 240 VAC (+10% - 15%)
频率
50/60 Hz
消耗功率
388 VA typ.
输出电流
12.5 A (rating)
涌入电流(typ)
55 A (at 100 VAC), 84 A (at 240 VAC) from a cold start
对地泄漏电流
3.5 mA max. (264 VAC, 60 Hz, with no load)
绝缘耐压・绝缘电阻(输入-FG)
1,500 VAC for one minute, Cutoff current: 20 mA 500 VDC, 20 MΩ min.
调光
Manual: Operation on the front panel, 256 or 1,024 levels External: Command input via TCP/IP or UDP/IP communications or Signal input through parallel port
输出端口
SRCN2A16-7S x 2, ELR-02V x 2
适合规格
CE, UKCA, RoHS
使用温湿度
Temperature: 0 to 40°C, Humidity: 20 to 85%RH (no condensation)
保存温湿度
Temperature: -20 to 60°C, Humidity: 20 to 85%RH (no condensation)
冷却方式
强制冷却
重量
2,400 g max.
材质
Steel sheet, Cover thickness: 1.0 mm, Chassis thickness: 1.6 mm, N3 (leather tone)
附属品
Instruction Guide, 2-m-long 3-prong AC power cord with ground terminal
Program
【Sample Program】 Sample programs are available. See the 选件 tab.
