43 VDC max., 293 W max. (including 36 W max. for fans)
通道数
1 channel
发光方式
常时发光
驱动方式
Constant-current system
调光方式
可变电流控制
输入电压
100 to 240 VAC (+10%, -15%)
频率
50/60 Hz
消耗功率
360VA typ.
涌入电流(typ)
55 A (at 100 VAC), 84 A (at 240 VAC) from a cold start
调光
Set the Manual/External switch (MODE) to Manual. Set any of 256/1000 steps via the setting switch (Parallel communications: Adjustment to 256 steps only). Press and hold the switch for 2 seconds to lock the light intensity value.
错误检测显示
On the Digital display
错误检测输出
Parallel communication: Output at pins 19 and 20: Photocoupler insulation, open collector output, short circuit at alert (load current of 10 mA or less)
EIA-485 communication: Checked by using a status command through EIA-485 communication
Ethernet communication: Checked by using a status command through TCP/IP or UDP/IP communication
输出端口
Metal connector PRC04-21A20S-19F (Tajimi Electronics co.,ltd)
外部控制端口
ON/OFF control (available in any light intensity control modes): MIL connector, 10 pins XG4A-1031 (manufactured by OMRON) Light intensity control (for Parallel communications): MIL connector, 20 pins XG4A-2031 (manufactured by OMRON) Light intensity control (for EIA-485 communications): e-con connector, 3 pins Light intensity control (for Ethernet communications): RJ-45 connector
适合规格
CE, UKCA, RoHS
使用温湿度
Temperature: 0 to 40°C, Humidity: 20 to 85%RH (no condensation)
保存温湿度
Temperature: -20 to 60°C, Humidity: 20 to 85%RH (no condensation)
冷却方式
Forced air cooling
重量
3100 g
材质
Steel sheet, Cover thickness: 1.0 mm, Chassis thickness: 2.0 mm, N3 (leather tone)
附属品
Instruction Guide, 2m long 3-prong AC power cord with ground terminal, Two locking Keys
Program
【Sample Program】 Sample programs are available. See the 选件 tab.
