Metal connector (L1-1, L1-2/L2-1,L2-2): 24 V, 300 W (1 connector 300 W or less) EL connector (L1-3, L1-4/L2-3,L2-4): 24 V, 300 W (1 connector 150 W or less) All 1 connectors total : 300 W or less (same as L2 connectors)
通道数
2 channels
发光方式
常时发光
驱动方式
Constant lighting
调光方式
可变电压控制
频率
50/60 Hz
输入电流
100 to 240 VAC (+10% - 15%)
消耗功率
765 VA typ.
输出电流
12.5 A/channel, Total for 2 channels:25 A
涌入电流(typ)
55 A / 95 A (promary/secondary values, at 100 VAC), 132 A / 132 A promary/secondary values, (at 240 VAC) from a cold start
对地泄漏电流
3.5 mA max. (264 VAC, 60 Hz, with no load)
绝缘耐压・绝缘电阻(输入-FG)
1,500 VAC for one minute, Cutoff current: 20 mA 500 VDC, 20 MΩ min.
输出端口
SRCN2A16-7S x 4, ELR-02V x 4
适合规格
CE, UKCA, RoHS
使用温湿度
Temperature: 0 to 40℃, Humidity: 20% to 85%RH (with no condensation) Altitude: 2000 m max.
保存温湿度
Temperature: -20 to 60°C, Humidity: 20 to 85%RH (no condensation)
冷却方式
强制冷却
重量
4100 g max.
材质
Steel sheet, Cover thickness: 1.0 mm, Chassis thickness: 1.6 mm, N3 (leather tone)
附属品
Instruction Guide, 2-m-long 3-prong AC power cord with ground terminal
Program
【Sample Program】 Sample programs are available. See the 选件 tab.
